The TYPE-81M12 is a compact and portable design, and makes a highly accurate and reliable fusion splice in high speed.
The TYPE-81M12 achieves splice time of approximately 14 seconds for SMF12c and heat shrink time of approximately 45 seconds with 40mm sleeve for 12c.
Independent dual heat shrink ovens which a.c built onto the splicer ran reduce the bottle neck of wait time and enhance splicing efficiency.
Automatic fiber count detection and automatic arc compensation function enable to automatically select suitable splice program for the fiber being used prior to fusion splicing.
A touch screen is available on 4.1 inch TFT color LCD monitor. An operator can just touch icons on the monitor to work with the splicer, which makes splicing operation more user-friendly,
The TYPE-81M12 has drip proof and dust proof performance equivalent to IP52. Rubber shook pads are equipped with the splicer to protect it from drop impact.
- Compact & Lightweight with 2.0 kg weight including battery
- Ultra fast splicing (14 sec for 12F Ribbon)
- Ultra fast heating (45 sec for 12F Ribbon )
- Dust-free, water resistant and shock-proof.
- Touch-screen operation
- Remote support via internet
- Upgrades software via internet
- Remote interactive maintenance via internet
- [326 KB]
